Steel Pipe Weight Calculator

Formula: WT/FT = (OD – WALL) X WALL X 10.69

Steel Pipe Weight Calculator

Outer Diameter (inches)

Wall Thickness (inches)

Result will be displayed here

Steel Pipe Wall Thickness

If you would like to directly check the weight of the steel pipe, you can also click the link below.

STEEL PIPE WEIGHT CHART PER FOOT

Nominal wall thickness for seamless and welded steel pipes according ANSI B36.10:

NPS(in)	Outside Diameter(in)	Schedule
		10	20	30	STD	40	60	XS	80	100	120	140	160	XXS
		Wall Thickness (in)
1/8	0.405				0.068	0.068		0.095	0.095
1/4	0.54				0.088	0.088		0.119	0.119
3/8	0.675				0.091	0.091		0.126	0.126
1/2	0.84				0.109	0.109		0.147	0.147				0.187	0.294
3/4	1.05				0.113	0.113		0.154	0.154				0.219	0.308
1	1.315				0.133	0.133		0.179	0.179				0.25	0.358
1 1/4	1.66				0.14	0.14		0.191	0.191				0.25	0.382
1 1/2	1.9				0.145	0.145		0.2	0.2				0.281	0.4
2	2.375				0.154	0.154		0.218	0.218				0.344	0.436
2 1/2	2.875				0.203	0.203		0.276	0.276				0.375	0.552
3	3.5				0.216	0.216		0.3	0.3				0.438	0.6
3 1/2	4				0.226	0.226		0.318	0.318
4	4.5				0.237	0.237		0.337	0.337		0.438		0.531	0.674
5	5.563				0.258	0.258		0.375	0.375		0.5		0.625	0.75
6	6.625				0.28	0.28		0.432	0.432		0.562		0.719	0.864
8	8.625		0.25	0.277	0.322	0.322	0.406	0.5	0.5	0.594	0.719	0.812	0.906	0.875
10	10.75		0.25	0.307	0.365	0.365	0.5	0.5	0.594	0.719	0.844	1	1.125	1
12	12.75		0.25	0.33	0.375	0.406	0.562	0.5	0.688	0.844	1	1.125	1.312	1
14	14	0.25	0.312	0.375	0.375	0.438	0.594	0.5	0.75	0.938	1.094	1.25	1.406
16	16	0.25	0.312	0.375	0.375	0.5	0.656	0.5	0.844	1.031	1.219	1.438	1.594
18	18	0.25	0.312	0.438	0.375	0.562	0.75	0.5	0.938	1.156	1.375	1.562	1.781
20	20	0.25	0.375	0.5	0.375	0.594	0.812	0.5	1.031	1.281	1.5	1.75	1.969
22	22	0.25	0.375	0.5	0.375		0.875	0.5	1.125	1.375	1.625	1.875	2.125
24	24	0.25	0.375	0.562	0.375	0.688	0.969	0.5	1.219	1.531	1.812	2.062	2.344
30	30	0.312	0.5	0.625	0.375			0.5
32	32	0.312	0.5	0.625	0.375	0.688
34	34	0.312	0.5	0.625	0.375	0.688
36	36	0.312	0.5	0.625	0.375	0.75
42	42		0.5	0.625	0.375	0.75
